Choose from 30.2 cup / 26.4 race or 30.0 cup / 27.0 race
- Material: High tension steel
- Color: Satin silver
- Triple sealed mechanism
- Fits 1" threaded forks
Technical Information:
- Top Lock Nut: 7.5mm (8 flats 32mm width, 5mm threading, with seal)
- Key Washer: 2.0mm
- Adjusting Cup: 12.3mm (8 flats 32mm width, 5.5mm threading)
- Upper Stationary Cone: 12.5mm (Insertion 30.2mm or 30.0mm)
- Lower Stationary Cup: 16.5mm (Insertion 30.2mm or 30.0mm)
- Crown Race: 6.0mm (26.4mm or 27.0mm)
- Ball Retainer x 2: #350 (5/32"x20 Balls)
- Seal ring x 2
